The Label space refers to the scope of labels in a given LSR. It determines assignment and distribution of labels to a given peer. During data flow, it decides the key for looking up MPLS table and takes appropriate action based on the entry. Label space is designated either as platform label space or per-interface label space.

In this implementation, a label must be unique for the entire platform. A label will be interpreted the same way at all the interfaces. The FIB entry in the router does not contain incoming interface related information. Thus the incoming traffic will be matched only with the label.

In this implementation, a label must be unique for a given input interface. A label will be interpreted Uniquely at different interface which allows us to re-use label for different entries. The FIB entry in router must contain incoming interface information along with label. Thus the incoming traffic will be matched with label and incoming interface.
