Topology
Figure 6-6: ISIS Segment routing with mapping server and LDP
In Figure 6-6:
• PE1 and PE2 are in a OSPF segment routing domain.
• P1 and P2 configured as mapping servers.
• PE3 and PE4 are in OSPF with LDP domain.
